🧰 Diagbox 9.200 Installation Tutorial (Windows 8, 10, 11)

This guide will walk you through the process of installing Diagbox 9.200 on your Windows computer, clearly and securely.

✅ Compatible with Windows 8, 10 and 11 – 64-bit only

⚠️ Important prerequisites

Before starting the installation, it is essential to:

• Temporarily disable your antivirus and Windows Defender

• Perform all steps as administrator

• Use a Windows account with administrator privileges

👉 These precautions prevent blockages, file deletions or installation errors.

🗂️ Step 1 – Download and decompress

1. Download the following archive: Diagbox v9.200 10-2024.zip

2. Extract the archive to a regular folder using WinRAR or 7-Zip.

3. Once the extraction is complete, verify that all files are present in the folder.

☕ Step 2 – Java Installation (required)

Diagbox requires Java to function correctly.

If Java is not already installed on your computer, you must install the following two versions :

• jre-8u411-windows-x32.exe

• jre-8u411-windows-x64.exe

⚠️ Both 32-bit and 64-bit versions are required , even on a 64-bit Windows system.

Restart your computer after installing Java.

🧱 Step 3 – Creating and excluding the AWRoot folder

1. Create the following folder: C:\AWRoot

2. This folder must be excluded from your antivirus and Windows Defender.

➕ Exclude AWRoot in Windows Defender

• Windows Settings → Update & Security → Windows Security

• Protection against viruses and threats

• Manage settings

• Add or remove exclusions

• Add an exclusion → Folder

• Select C:\AWRoot and confirm.

🧩 Exclude AWRoot from your antivirus

• Open your antivirus software

• Search Exclusions / Exceptions / Excluded Files

• Add the path: C:\AWRoot

💿 Step 4 – Installing Diagbox 9.200

1. Open the previously extracted folder.

2. Launch the file: Diagbox v9.200 10-2024.exe (right-click → Run as administrator )

3. Follow the on-screen instructions until the installation is complete.

⏳ The installation may take several minutes. Do not close the window until the process is complete.

🔌 Step 5 – Installing the PSA XS Evolution sensor drivers

To ensure your interface is correctly recognized:

1. Connect the PSA XS Evolution probe to your computer.

2. Open Device Manager

3. Locate the unrecognized device (yellow exclamation mark)

4. Right-click → Update driver

5. Select Browse my computer for a driver

6. Specify the following path: C:\AWRoot\extra\Drivers

7. Confirm and let Windows install the driver.

🔄 Step 6 – Finalizing the installation

1. Restart your computer

2. Launch Diagbox (right-click → Run as administrator )

3. Check that the probe is correctly detected in the software

❗ Common problems and solutions

Diagbox fails to launch or displays an error

• Check that your antivirus and Windows Defender are disabled.

• Verify that C:\AWRoot is still excluded

The probe is not recognized

• Check the driver installation

• Try a different USB port

• Restart the driver installation from C:\AWRoot\extra\Drivers

License or activation error

• Check that all the steps have been followed.

• Make sure the AWRoot folder has not been moved or renamed

🎯 Conclusion

The installation of Diagbox 9.200 is now complete.

You can now use the software to perform your PSA diagnostics under good conditions of stability and operation.
