📌 Tutorial: Installing MPPS V22D
1️⃣ Downloading and Extracting
-
Download the file
MPPS_V22D.zip.
-
Extract the compressed folder:
- Right-click on the downloaded file.
- Select "Extract all..." or use WinRAR .
-
- Choose a location (by default, a folder is created in the same location as the ZIP file).
- Click on "Extract" .
2️⃣ Software Installation
-
Open the
MPPS_V22Dfolder.
-
Launch the executable file
mpps_setup_revD.exeto start the installation.
- Choose the language , then click OK .
- Follow the installation steps by clicking "Next" until the end.
-
Do not run MPPS immediately :
- At the end of the installation, uncheck the box that offers to open MPPS.
- Click on "Finish" .
3️⃣ Installing the drivers
-
Open Device Manager :
- Type "Device Manager" in the Windows search bar and open it.
- Connect the MPPS tool to the computer.
-
Identify the error :
- An "Amt Flash 2 (USB)" line appears with an error.
- An "Amt Flash 2 (USB)" line appears with an error.
-
- Double-click on it, then select "Update driver..." .
-
Install the driver manually :
- Choose "Browse my desktop to search for drivers" .
-
- Specify the path to the
Driversfolder, which is located by default in:C:\MPPS\Device Driver
- Specify the path to the
-
- Click "Next" and confirm the driver installation.
-
Verification :
-
Amt Flash 2is now correctly recognized.
-
-
- You can close Device Manager .
✅ Launch of MPPS
Installation complete! You can now open MPPS and start using it. 🚀
