Complete tutorial for installing DIALOGYS 4.90 on Windows

This guide details step-by-step the installation of DIALOGYS 4.90 (Renault / Dacia parts catalogue) from the provided ISO files.

1. System Requirements

Operating system

• Windows 7, 8, 10 or 11 (32/64 bit)

• User account with administrator rights

Required software (to be installed BEFORE Dialogys)

• Java Runtime Environment (JRE) compatible

  • Recommended: Java 8 (32 or 64-bit depending on your system)

• Adobe Reader (for opening PDF documents)

⚠️ Tip:

• Temporarily disable your antivirus software during installation.

• Avoid paths with special characters or accents

2. Required files

You must have all the ISO files downloaded in full and in the following order :

• CD0-Dialogys_1.6_v7.6.5_Without_Alpine_23_03_2018.iso

• dvd1.iso

• dvd2.iso

• dvd3.iso

• dvd4.iso

• dvd5.iso

• dvd6.iso

• dvd7.iso

⚠️ All DVDs are essential for a complete foundation.

3. Preparation before installation

1. Create a dedicated folder (example: C:\Dialogys_ISO )

2. Place all ISO files in this folder

3. Verify that each ISO file can be mounted without error.

To mount an ISO image:

• Right-click → Mount (Windows 8+)

• Or use a virtual drive software if you're using Windows 7 (Daemon Tools, WinCDEmu…)

4. Step-by-step installation

Step 1 – Installing CD0 (required)

1. Mount the file:

   • CD0-Dialogys_1.6_v7.6.5_Without_Alpine_23_03_2018.iso

2. Open the newly created virtual CD drive.

3. Locate the file:

   • InstallLauncher.bat

4. Right-click → Run as administrator

5. Follow the on-screen instructions

   • Do not change the default paths unless necessary.

6. Wait until the installation is completely finished.

7. Close all windows

8. Eject CD0 (right-click on the drive → Eject)

Step 2 – Installing the data DVDs (DVD1 to DVD7)

The procedure is exactly the same for each DVD .

Example with DVD1:

1. Mount the dvd1.iso file

2. Open the virtual CD drive

3. Launch:

   • InstallLauncher.bat (always run as administrator)

4. Allow the installation to complete.

5. Close the program

6. Eject the virtual DVD

Repeat the exact same procedure for:

• dvd2.iso

• dvd3.iso

• dvd4.iso

• dvd5.iso

• dvd6.iso

• dvd7.iso

⚠️ Important:

• Install only one DVD at a time

• Never mount two ISOs simultaneously

• Always wait until the end is complete before moving on to the next one.

5. First launch of DIALOGYS

1. Once all the DVDs are installed:

   • Open the Start menu

   • Search Dialogys

2. Launch the program

   • The first startup may take longer than subsequent ones.

3. Check that:

   • The catalogs open correctly

   • The PDFs are displayed (Adobe Reader)

6. Routine Troubleshooting

Dialogys does not start

• Verify that Java is properly installed

• Testing another version of Java 8

• Launch Dialogys as administrator

PDFs won't open

• Check Adobe Reader

• Reset PDF file association

Installation stuck on a DVD

• Corrupted ISO → re-download the affected file

• Active antivirus → temporarily disable

7. Practical advice

• Avoid using external hard drives or USB flash drives during installation.

• Install on a disk with at least 20 GB of free space

• Keep the ISO files after installation (backup)

8. Quick summary

1. Install Java + Adobe Reader

2. Mount CD0 → InstallLauncher.bat

3. Eject CD0

4. Install DVD1 through DVD7 , one by one

5. Launch Dialogys

Installation complete. DIALOGYS 4.90 is ready for use.
