Installation and activation tutorial

Renault CAN CLIP V192

This guide describes step by step the correct procedure to install and activate Renault CAN CLIP V192 .
Strict adherence to each step is essential to avoid errors in installation, activation or recognition of the probe.

✅ MANDATORY PREREQUISITES

Before you begin, be sure to check the following points:

• Operating system : Windows 7 – 32-bit only

• Administrator rights on the Windows session

• Antivirus temporarily disabled (during the entire installation process)

• WinRAR is required for all extractions.

• ❌ Never launch CAN CLIP before the activation process is complete.

⚠️ Any attempt to install on another system (Windows 10/11, 64-bit, poorly configured VM) will result in malfunction.

📥 STEP 1 – Downloading and preparing the files

1. Downloading the software

Download the following archive:
Can Clip V192_0_2_0.rar

2. Software extraction

• Right-click → Extract with WinRAR

• Extract the contents to a standard folder on your computer.
  (examples: Office or Documents)

3. Activation Download

Then download the archive:
CAN CLIP Activation and Patch (-V212).zip

4. Activation Extraction

• Extract using WinRAR only

• Do not change the folder structure

⚠️ Important points

• Do not launch any files until all archives are fully extracted.

• Never use the Windows extractor

• Keep the two extracted folders accessible for later use.

🔧 STEP 2 – Installing the CAN CLIP software

1. Open the extracted CAN CLIP V192 folder

2. Before any installation , run:

    01. Renault CLIP.reg


   → Accept the addition to the registry

1. Next, launch the installation via the setup.

2. Accept the driver installation when prompted.

3. The computer will restart.

⚠️ At the end of the installation:
❌ DO NOT LAUNCH CAN CLIP

🔐 STEP 3 – Software Activation

⚠️ This step is critical. Follow the order exactly.

1. Go to the folder:

    C:\CLIP_X91\Lib\Application\


2. Launch the RSRWin.exe file (original version)

3. Click on "Register me now"

4. To the next question, choose "NO"

5. Carefully note the serial number displayed.

Key generation

6. Launch one of the following tools (KEYGEN folder):

   • Renault CLIP TOOL

   • or Renault Can Clip Registration

7. Generate the key from the serial number

8. Enter the key in RSRWin.exe

9. Confirm

✅ Activation successfully completed

🔌 STEP 4 – Probe recognition patch (RTL2002)

To ensure correct recognition of the RTL2002 probe:

1. Go to the folder:

    C:\CLIP\Config\


2. Replace the following files:

   • probesConfiguration.xml

   • probesConfiguration_logs.xml

3. By those provided in folder 03 of the activation archive

⚠️ Ensure that CAN CLIP is completely closed during this operation.

🚗 Access for vehicles manufactured before 2005

To allow access to older vehicles:

1. Copy the file:

    IsoDrv.dll


   from file 03

2. Paste it into:

    C:\Program Files\Common Files\SAGEM SA\






🔹 Connecting the CAN CLIP probe

Before the opening of CAN CLIP

1. Connect the CAN CLIP probe's OBD2 cable to the vehicle's OBD port.

2. Turn the vehicle's ignition on ( ON position, engine not started)

👉 The CAN CLIP probe must be powered by 12V .
Without vehicle power, the probe will not be detected by CAN CLIP.

3. Next, connect the CAN CLIP probe to the PC via USB.

Checking proper operation

• The two red LEDs on the probe should light up

• When CAN CLIP is launched, the 2 green LEDs also light up

You can confirm that the probe has been correctly detected in the Windows Device Manager :

• Two devices should appear:

  • Bosch Automotive – RTL2002 CAN Communication Interface (After re-enumeration)

  • Bosch Automotive – RTL2002 ISO Communication Interface (After re-enumeration)

👉 If these two lines are present, the probe is correctly recognized.

Software launch

You can now launch CAN CLIP normally.

✅ INSTALLATION COMPLETE

Renault CAN CLIP V192 is ready to be used.

In case of a problem

• Verify that the system used is indeed Windows 7 – 32-bit

• Check that the antivirus has not deleted any necessary files.

• Check that CAN CLIP was not launched before activation.
