Function to be activated via VCDS - VAG-COM software
Option description:
Enables activation of Audi Drive Select Individual and its management with the MMI.
Step 1: Activate ADS in the Power Plant
[09 – Power Plant] -> [Coding- 07] -> [Long Coding Helper]
Octet 7:
Bit 5: Check “Drive Select installed”
[09 – Power Plant] -> [Coding- 07] -> [Long Coding Helper]
Octet 8:
Bit 1: Check "Enable Steering in ADS" (Activates Dynamic Steering)
Bit 2: Check "Enable Engine in ADS Menu" (Enable engine/transmission)
Bit 3: Check "Enable Suspension in ADS Menu" (Activates adaptive damping)
Bit 4: Check "Enable Steering in ADS Menu" (Activates Dynamic Steering)
Bit 5: Check "Enable Sport Differential in ADS Menu" (Activates the sport differential)
[09 – Power Plant] -> [Coding- 07] -> [Long Coding Helper]
Octet 17:
Bit 7: Check the box
[09 – Power Plant] -> [Security Access – 16] (20113) -> [Adaptation – 10] -> Channel 63
Enter the value 4 (Individual)
[09 – Power Plant] -> [Security Access – 16] (20113) -> [Adaptation – 10] -> Channel 64
Enter the value 4 (Individual)
[09 – Power Plant] -> [Security Access – 16] (20113) -> [Adaptation – 10] -> Channel 65
Enter the value 4 (Individual)
[09 – Power Plant] -> [Security Access – 16] (20113) -> [Adaptation – 10] -> Channel 66
Enter the value 4 (Individual)
Step 2: Activate the menu in the MMI
For the MMI Basic Plus
[07 – Control Head] -> [Adaptation -10] -> Channel 01
Add 32 to the existing value
For the MMI 2G
Launch the Hidden Menu by pressing SETUP + CAR (for 6 seconds)
DIAG SETTINGS -> Car Menu Mask -> Charisma -> Check the box
Don't forget to confirm the changes by selecting "Accept changes".
For the MMI 3G
Launch the Hidden Menu by pressing SETUP + CAR (for 6 seconds)
car -> carmenuoperation -> charisma -> select "5"
Press "Return"
car -> cardevicelist -> charisma -> check the box
Reboot the MMI by pressing SETUP + Scroll Wheel + Top Right Button.
