Function to be activated via VCDS - VAG-COM software
Option description:
Enables the display of reversing radars on the MMI, for vehicles that only have the Audi Rear Parking System option.
On some vehicles equipped with module 8X0-919-475-F, activation does not work.
No problems for vehicles equipped with module 8X0-919-475-M
[10 – Parking Assistance] -> [Security -16] (code 71679) -> [Coding-07] -> [Long Coding Assistant]
Byte 0:
Bit 2-3: Check “08 Optical Illustration active (BAP NEW)”
Restart the MMI
Method 1
Maintain MENU (1) + Wheel (2) + Top Right Button (3) for 6 seconds.
Method 2 (if method 1 does not work)
Press and hold BACK (1) + Scroll Wheel (2) + Top Right Button (3) for 6 seconds.
[10 – Parking assistance] -> [Adaptation – 10] -> Select Visual display for park assist from the drop-down list
Change the value with OPS Display
