Function to be activated via VCDS - VAG-COM software
Option description:
Allows you to activate the corner lights with the fog lights.
[09 – Power Plant] -> [Security Access – 16] 31347 -> [Adaptation – 10] -> "(9)-Leuchte12NL LB45-Lichtfunktion D 12" in the drop-down list
Select “Abbiegelicht links”
[09 – Power Plant] -> [Security Access – 16] 31347 -> [Adaptation – 10] -> “(10)-Leuchte12NL LB45-Dimmwert CD 12” in the dropdown list
Enter "100"
[09 – Power Supply] -> [Security Access – 16] 31347 -> [Adaptation – 10] -> "(11)-Leuchte12NL LB45-Dimming Direction CD 12" in the dropdown list
Select "maximize"
[09 – Power Plant] -> [Security Access – 16] 31347 -> [Adaptation – 10] -> "(9)-Leuchte13NL RB5-Lichtfunktion D 13" in the dropdown list
Select “Abbiegelicht rechts”
[09 – Power Plant] -> [Security Access – 16] 31347 -> [Adaptation – 10] -> "(10)-Leuchte13NL RB5-Dimmwert CD 13" in the dropdown list
Enter "100"
[09 – Power Plant] -> [Security Access – 16] 31347 -> [Adaptation – 10] -> "(11)-Leuchte13NL RB5-Dimming Direction CD 13" in the dropdown list
Select "maximize"
