Function to be activated via VCDS - VAG-COM software
Option description:
Enables Lane Assist for vehicles with Sign Assist option.
[17 – Instruments] -> [Coding – 07] -> [Long Coding Assistant]
Octet 4:
Bit 6: Check “Lane Maintenance Assist installed”
[17 – Instruments] -> [Coding – 07] -> [Long Coding Assistant]
Octet 11:
Bit 1: Check “Lane Maintenance Assist information (BAP) installed/active”
[A5 – Frt Sens. Drv. Assist] -> [Security – 16] (20103) -> [Coding – 07] -> [Long Coding Assistant]
Byte 0:
Bits 0-7: Select "01 coding_HCA coded"
[A5 – Frt Sens. Drv. Assist] -> [Security – 16] (20103) -> [Adaptation – 10] -> HCA_Warning_intensity
Set the value to "Menu"
[A5 – Frt Sens. Drv. Assist] -> [Security – 16] (20103) -> [Adaptation – 10] -> BAP_Personalisierung
Set the value to "not activated"
[A5 – Frt Sens. Drv. Assist] -> [Security – 16] (20103) -> [Adaptation – 10] -> Personalization of lane dept. warning Cl. 15 on
Set the value to "last setting"
[44 – Steering Assist] -> [Security – 16] (19249) -> [Coding – 07] -> [Long Coding Assistant]
Byte 0:
Bit 4: Check “Lane Assist installed”
[5F – Electr. Information] -> [Adaptation – 10] -> (49)-Vehicle function list BAP-LDW_HCA_0x19
Set the value to "activated"
[5F – Electr. Information] -> [Adaptation – 10] -> (21)-Vehicle menu operation menu_display_Lane_Departure_Warning
Set the value to "activated"
[5F – Electr. Information] -> [Adaptation – 10] -> (23)-Vehicle menu operation-menu_display_Lane_Departure_Warning_over_threshold_high
Set the value to "activated"
